Introduction

This article addresses the issue of low memory errors encountered while running G-code on a CNC machine controlled by FluidNC firmware on a Jackpot TMC2209 board. The specific error message, [MSG:WARN:: Low memory: 14200 bytes], indicates that the controller is running out of memory during operation, leading to work stoppage. This comprehensive guide will delve into the causes of this problem, explore potential solutions, and provide a detailed walkthrough to resolve low memory issues in FluidNC.

Understanding the Problem: Low Memory in FluidNC

When dealing with low memory issues in FluidNC, it's essential to understand the root cause. The error message [MSG:WARN:: Low memory: 14200 bytes] signifies that the microcontroller's available memory is insufficient to process the current G-code commands. This can manifest as the machine halting mid-operation, leading to wasted material and time. Several factors can contribute to low memory, including:

  • Complex G-code: G-code files with intricate curves, numerous small segments, or high resolution can consume a significant amount of memory. The controller needs to store and process these commands, and a complex file can quickly exhaust available resources.
  • Configuration Overhead: The FluidNC configuration file (config.yaml) dictates various machine parameters, such as motor settings, axis limits, and homing cycles. An overly complex or verbose configuration can increase memory usage.
  • Planner Buffer: FluidNC uses a planner buffer to store upcoming G-code commands, allowing for smoother motion. A larger planner buffer consumes more memory but can improve performance. An insufficient buffer can lead to stuttering or pauses, while an excessively large buffer can contribute to low memory.
  • Report Intervals: Frequent status reports from the controller to the user interface (e.g., WebUI) can consume memory and processing power. Reducing the frequency of these reports can alleviate memory pressure.
  • Hardware Limitations: The ESP32 microcontroller, while powerful, has a finite amount of RAM. If the memory requirements of the G-code, configuration, and other processes exceed this limit, low memory errors will occur.

To effectively tackle this issue, we will explore a range of troubleshooting steps, focusing on optimizing the G-code, refining the configuration, and managing report intervals. By systematically addressing these factors, we can enhance the performance and stability of your CNC machine.

Analyzing the Configuration File

In addressing the issue of low memory, the configuration file (config.yaml) is a critical area to examine. This file dictates how FluidNC operates, and its settings can significantly impact memory usage. Let's break down the key sections of the provided configuration and identify potential optimizations.

Stepping Configuration

The stepping section defines how FluidNC controls the stepper motors. The engine: I2S_STATIC setting utilizes the ESP32's I2S peripheral for precise step generation, which is generally efficient. The idle_ms: 255 parameter sets the delay before motors are disabled when idle. While this saves power, a longer delay consumes slightly more memory. A reasonable balance should be struck here. The pulse_us, dir_delay_us, and disable_delay_us settings define timing parameters for the step signals. These values are typically fine-tuned for specific hardware but don't significantly impact memory.

UART1 Configuration

The uart1 section configures the serial communication port used for TMC2209 stepper driver communication. The baud rate of 115200 is standard and doesn't pose a memory concern. The mode: 8N1 setting (8 data bits, no parity, 1 stop bit) is typical. If any issues arise, ensuring these settings match the stepper driver configuration is key.

Axes Configuration

This is where the bulk of the memory usage can be influenced. Each axis (X, Y, Z) has extensive settings that need careful review. Key parameters include:

  • steps_per_mm: This value determines the resolution of the axis and should be accurate for the mechanical setup. While not a direct memory consumer, an excessively high value can lead to more complex G-code commands.
  • max_rate_mm_per_min and acceleration_mm_per_sec2: These parameters define the maximum speed and acceleration of the axis. While essential for performance, they don't significantly impact memory.
  • max_travel_mm and soft_limits: These settings define the machine's workspace. It's crucial to set these accurately to prevent crashes. Soft limits can consume a small amount of memory, but they are vital for safety.
  • homing: The homing cycle settings define how the machine finds its origin. Complex homing sequences with multiple cycles can increase memory usage. It's worth examining if the sequence can be simplified without sacrificing accuracy.
  • motor0 and motor1: These subsections define the motor settings for each axis. The limit_neg_pin and limit_pos_pin parameters define the limit switch pins. Hard limits are crucial for preventing damage, but they don't impact memory significantly. The tmc_2209 subsection contains settings specific to the TMC2209 stepper drivers.

TMC2209 Configuration

  • uart_num and addr: These parameters define the UART port and address of the TMC2209 driver. These are essential for communication but don't consume much memory.
  • r_sense_ohms: This value is critical for current regulation and should be accurate for the sense resistors used. It has no impact on memory.
  • run_amps, homing_amps, and hold_amps: These settings define the motor current levels. It's crucial to set these appropriately to avoid overheating or stalling. These parameters don't affect memory.
  • microsteps: This is a critical setting. Higher microstep values (e.g., 16 or 32) provide smoother motion but increase the number of steps per millimeter, leading to more complex G-code and higher memory usage. Reducing the microsteps to 8 or even 4 can significantly reduce memory consumption, especially for machines with high steps_per_mm values. This adjustment should be done carefully, considering the trade-off between smoothness and memory usage. For example, the configuration shows microsteps: 8, which is a good starting point, but experimenting with lower values may be beneficial.
  • stallguard: This feature detects motor stalls. If not needed, disabling it can save a small amount of memory.
  • toff_disable, toff_stealthchop, and toff_coolstep: These parameters control the driver's turn-off settings. Optimizing these can improve efficiency but doesn't significantly impact memory.
  • run_mode and homing_mode: These settings define the driver's operating mode (e.g., StealthChop for quiet operation). These don't consume significant memory.
  • use_enable: This parameter controls the driver enable pin. If not needed, disabling it can save a pin but not memory.
  • step_pin, direction_pin, and disable_pin: These define the pin assignments for the stepper motor signals. They are essential for proper wiring but don't impact memory.

Other Configuration Sections

The remaining sections of the configuration file (i2so, spi, sdcard, probe, start, coolant, control, macros, user_outputs, laser, pwm) define various machine features and peripherals. While these sections are essential for functionality, they generally don't consume significant amounts of memory compared to the axes configuration. However, it's worth reviewing these sections to ensure no unnecessary features are enabled.

Key Configuration Optimizations

Based on the configuration analysis, the most impactful memory optimization is likely to be reducing the microsteps value in the tmc_2209 subsections of the axes configuration. Experimenting with values of 8 or 4 can significantly reduce memory consumption. If stall detection is not needed, consider disabling stallguard. Remember to save the changes to your config.yaml file and restart FluidNC for the new settings to take effect.

Analyzing the G-Code File

The G-code file itself is a significant contributor to memory usage. Complex toolpaths, intricate curves, and high-resolution settings can result in large files that strain the controller's memory. To address this, we need to understand how G-code complexity affects memory and explore optimization strategies. The provided G-code excerpt showcases a toolpath generated by FreeCAD, involving a profile operation with numerous G2 and G3 commands (arc movements).

Understanding G-Code Complexity

  • Arcs and Curves (G2/G3): These commands, representing circular or helical arcs, require the controller to perform calculations and generate intermediate points. The more arcs and curves in a file, the higher the memory demand.
  • Linear Moves (G1): While seemingly simpler, a large number of short linear moves can also contribute to memory load. This often occurs when approximating curves with many small line segments.
  • Resolution and Tolerance: The resolution or tolerance settings used during G-code generation dictate the number of points needed to represent a curve. Finer resolutions result in smoother curves but create larger G-code files.
  • File Size: Generally, a larger G-code file implies greater memory usage. However, the type of commands and their complexity are more crucial than raw file size alone.

G-Code Optimization Strategies

  1. Simplify Toolpaths:

    • Reduce Complexity: Look for opportunities to simplify the design or toolpath strategy. Are there areas where the toolpath can be less intricate without compromising the final result?
    • Optimize CAM Settings: Adjust the Computer-Aided Manufacturing (CAM) software settings to generate more efficient G-code. This includes:
      • Tolerance: Increase the tolerance setting slightly. This allows the CAM software to approximate curves with fewer segments. A small increase in tolerance can significantly reduce file size without noticeably affecting the part's quality.
      • Arc Fitting: Ensure the CAM software is effectively using arc fitting. This converts a series of short line segments into arcs (G2/G3 commands), which are more memory-efficient.
      • Smoothing: Some CAM software offers smoothing features that reduce the number of abrupt changes in direction, leading to simpler G-code.

  2. Review Curve Approximation:

    • Minimize Short Segments: Identify areas in the G-code where curves are approximated with many short line segments. These can often be replaced with true arc commands (G2/G3).
    • Arc Optimization Tools: Explore G-code editing tools that can automatically convert sequences of linear moves into arcs. This process, sometimes called
