Introduction

When working with OVHcloud and Terraform, it's crucial to ensure that the IDs used across different resources are consistent and correctly formatted. A mismatch in ID formats can lead to errors during the deployment and management of cloud resources. This article addresses a specific issue encountered with the ovh_cloud_project_network_private resource and its interaction with the ovh_cloud_project_instance resource within the OVHcloud Terraform provider. The core problem revolves around the network ID format returned by ovh_cloud_project_network_private, which appears to be incompatible with the format expected by the network.private.network.id attribute in ovh_cloud_project_instance. This discrepancy results in a BadRequest error from the OVHcloud API, preventing instances from being created within the private network.

The error message indicates that the network ID, which is in a format like pn-1240644_0, does not conform to the UUID format expected by the API. This article delves into the specifics of the issue, including the Terraform configuration, versions, and steps to reproduce the problem. It also aims to provide a comprehensive understanding of the expected behavior and the actual behavior observed, along with potential solutions and workarounds. By addressing this issue, users can effectively manage their OVHcloud private networks and instances using Terraform, ensuring seamless deployments and operations.

Understanding the Bug

The bug manifests when the network ID obtained from the ovh_cloud_project_network_private resource is used in the network.private.network.id attribute of the ovh_cloud_project_instance resource. Terraform raises an error because the network ID format returned by ovh_cloud_project_network_private is not in the UUID format expected by the network.private.network.id attribute. This discrepancy leads to a BadRequest error from the OVHcloud API, preventing the successful creation of instances within the private network. The error message explicitly states that the provided network ID does not conform to the UUID type, highlighting a critical incompatibility between the resource outputs and inputs.

To further illustrate the issue, consider the typical workflow of creating a private network and then deploying an instance within that network. First, the ovh_cloud_project_network_private resource is used to provision a private network within the OVHcloud project. This resource returns a network ID, which is then intended to be used when creating an instance using the ovh_cloud_project_instance resource. However, the format of this network ID, such as pn-1240644_0, does not match the expected UUID format, causing the API to reject the request. This mismatch disrupts the intended workflow and requires a workaround to ensure successful instance deployment. Understanding this fundamental incompatibility is crucial for troubleshooting and resolving the issue.

Technical Details and Error Analysis

Error Message Breakdown

The error message provided is crucial for diagnosing the problem. It states:

Error: calling /cloud/project/18c0415850624984aa18d30587e95680/region/GRA9/instance with params &{<nil> <nil> hourly 0x14000620870 0 0x14000620660 <nil> web-gateway-prod 0x14000620a90 <nil> <nil> 0x14000620fc0}:
"OVHcloud API error (status code 400): Client::BadRequest: \"[network.private.network.id] Given data (pn-1240644_0) is not valid for type uuid\" (X-OVH-Query-Id: EU.ext-5.686bb838.2119704.22372dd5327ced04a59c56912bb7a926)"

with module.web_gateway.ovh_cloud_project_instance.instance,
on ../../modules/compute_instance/main.tf line 21, in resource \"ovh_cloud_project_instance\" \"instance\":
21: resource \"ovh_cloud_project_instance\" \"instance\" {

This message can be dissected into several key parts:

  • Error Origin: The error originates from the OVHcloud API, specifically when calling the /cloud/project/{service_name}/region/{region}/instance endpoint. This indicates that the issue occurs during the instance creation process.
  • Status Code: The status code 400 signifies a BadRequest error, meaning the request sent by Terraform to the OVHcloud API was malformed or contained invalid data.
  • Detailed Error: The core of the error message, [network.private.network.id] Given data (pn-1240644_0) is not valid for type uuid, clearly states that the value provided for the network.private.network.id attribute does not conform to the expected UUID format. The example value pn-1240644_0 is a typical OVHcloud private network ID format, which is not a UUID.
  • Terraform Context: The error message also provides the location within the Terraform configuration where the error occurred. In this case, it points to line 21 of the main.tf file within the compute_instance module, specifically the ovh_cloud_project_instance resource block.

Root Cause Analysis

The root cause of this issue lies in the discrepancy between the network ID format returned by the ovh_cloud_project_network_private resource and the format expected by the ovh_cloud_project_instance resource. The OVHcloud API expects the network.private.network.id to be a UUID, which is a 128-bit identifier typically represented as a string of 36 characters, such as xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx. However, the ovh_cloud_project_network_private resource returns a network ID in a different format, such as pn-1240644_0, which is a human-readable identifier but not a UUID.

This mismatch can stem from several factors:

  • API Inconsistency: The OVHcloud API might have inconsistencies in its requirements for different resources. Some endpoints might expect UUIDs, while others might use different formats.
  • Provider Implementation: The Terraform OVH provider might not be correctly translating or mapping the network ID format between resources. This could be due to a bug in the provider or a misunderstanding of the API requirements.
  • Documentation Gaps: The official documentation might not clearly specify the expected format for the network.private.network.id attribute, leading to confusion and errors.

Version Compatibility

The issue has been reported with Terraform v1.12.2 and the OVH Terraform provider v2.5.0. This suggests that the problem is not specific to a particular version but rather a persistent issue within the interaction between these components. It is essential to consider version compatibility when troubleshooting such issues, as newer versions might include fixes or workarounds. However, in this case, the problem seems to be inherent in the way the provider handles network IDs, regardless of the specific versions used.

Steps to Reproduce

To reproduce the issue, follow these steps:

  1. Define the Resources: Create a Terraform configuration file (main.tf) that defines both the ovh_cloud_project_network_private and ovh_cloud_project_instance resources.

  2. Configure the Private Network: Use the ovh_cloud_project_network_private resource to create a private network within your OVHcloud project. Specify the service_name and regions as required.

  3. Output the Network ID: Define an output variable to capture the ID of the private network created in the previous step. This output will be used in the next step.

  4. Create an Instance: Use the ovh_cloud_project_instance resource to create an instance within the private network. Reference the network ID obtained from the output variable in the network.private.network.id attribute. Additionally, specify other required attributes such as service_name, name, region, billing_period, flavor, boot_from, and ssh_key.

  5. Apply the Configuration: Run terraform apply to apply the configuration. Terraform will attempt to create the private network and the instance.

  6. Observe the Error: During the instance creation, Terraform will encounter the error message indicating that the network ID is not a valid UUID. This confirms the issue.

Example Configuration Files

Here are example Terraform configuration files that can be used to reproduce the issue:

resource "ovh_cloud_project_network_private" "private_network" {
  service_name = var.project_id
  regions      = [var.region]
  name         = "private-network"
}

output "network_id" {
  value = ovh_cloud_project_network_private.private_network.id
}

resource "ovh_cloud_project_instance" "instance" {
  service_name   = var.service_name
  name           = var.name
  region         = var.region
  billing_period = "hourly"
  flavor {
    # Find the flavor ID where the flavor's name attribute matches "b3-8"
    flavor_id = one([
      for flavor in data.ovh_cloud_project_flavors.all_flavors.flavors : flavor.id
      if flavor.name == "b3-8"
    ])
  }

  boot_from {
    image_id = one([
      for image in data.ovh_cloud_project_images.all_images.images : image.id
      if image.name == "Ubuntu 24.04"
    ])
  }
  ssh_key {
    name = var.ssh_key_name
  }

  network {
    private {
      network {
        id        = var.network_id
        subnet_id = var.subnet_id
      }
    }
  }
}

This configuration demonstrates the basic setup required to reproduce the issue. The ovh_cloud_project_network_private resource creates a private network, and the ovh_cloud_project_instance resource attempts to create an instance within that network. The output block exposes the network ID, which is then used in the ovh_cloud_project_instance resource.

Expected vs. Actual Behavior

Expected Behavior

The expected behavior is that the ovh_cloud_project_network_private resource should return a network ID in a format compatible with the network.private.network.id attribute of the ovh_cloud_project_instance resource. Ideally, the network ID should be a UUID, as this is the format expected by the OVHcloud API. When the Terraform configuration is applied, the private network and the instance should be created successfully, with the instance correctly attached to the private network.

Actual Behavior

In reality, the ovh_cloud_project_network_private resource returns a network ID in a format that is not a UUID, such as pn-1240644_0. This non-UUID format is incompatible with the network.private.network.id attribute of the ovh_cloud_project_instance resource. As a result, when Terraform applies the configuration, it fails to create the instance and returns a BadRequest error from the OVHcloud API. The error message clearly indicates that the provided network ID is not a valid UUID, highlighting the discrepancy in ID formats.

The actual behavior deviates significantly from the expected behavior, as the instance creation process is blocked due to the network ID format mismatch. This issue prevents users from effectively managing their OVHcloud resources using Terraform, as instances cannot be deployed within private networks using the standard configuration approach. The incompatibility between the network ID formats necessitates a workaround to achieve the desired outcome.

Potential Solutions and Workarounds

Identifying Subnet ID

One potential workaround involves identifying the subnet ID associated with the private network and using it in the instance configuration. The subnet ID is a UUID and is compatible with the network.private.network.id attribute. To implement this workaround:

  1. List Subnets: Use the ovh_cloud_project_private_network_subnet data source to list the subnets associated with the private network.

  2. Filter by Region: Filter the subnets by the region where the instance is being created.

  3. Use Subnet ID: Use the subnet ID obtained from the data source in the network.private.network.id attribute of the ovh_cloud_project_instance resource.

Example Configuration

Here’s an example configuration demonstrating this workaround:

data "ovh_cloud_project_private_network_subnet" "subnet" {
  service_name = var.service_name
  network_id   = ovh_cloud_project_network_private.private_network.id
  region       = var.region
}

resource "ovh_cloud_project_instance" "instance" {
  service_name   = var.service_name
  name           = var.name
  region         = var.region
  billing_period = "hourly"
  flavor {
    flavor_id = one([
      for flavor in data.ovh_cloud_project_flavors.all_flavors.flavors : flavor.id
      if flavor.name == "b3-8"
    ])
  }
  boot_from {
    image_id = one([
      for image in data.ovh_cloud_project_images.all_images.images : image.id
      if image.name == "Ubuntu 24.04"
    ])
  }
  ssh_key {
    name = var.ssh_key_name
  }
  network {
    private {
      network {
        id        = data.ovh_cloud_project_private_network_subnet.subnet.id
        subnet_id = data.ovh_cloud_project_private_network_subnet.subnet.id
      }
    }
  }
}

In this configuration, the ovh_cloud_project_private_network_subnet data source fetches the subnet associated with the private network. The id attribute of the subnet is then used in the network.private.network.id attribute of the ovh_cloud_project_instance resource. This ensures that a UUID is provided, resolving the error.

Reporting the Issue

Another crucial step is to report the issue to the OVH Terraform provider maintainers. This can be done by creating a new issue on the provider’s GitHub repository. Providing detailed information about the bug, including the Terraform version, provider version, configuration files, and error messages, will help the maintainers understand and address the issue more effectively. By reporting the issue, you contribute to the improvement of the provider and help other users avoid the same problem.

Provider Updates

Keep an eye on updates to the OVH Terraform provider. The maintainers might release a new version that includes a fix for this issue. Regularly checking for updates and upgrading the provider can help ensure that you are using the latest version with the most recent bug fixes and improvements. Provider updates are often the most effective way to resolve such issues, as they address the root cause of the problem within the provider’s code.

Contacting OVHcloud Support

If the issue persists or if you need further assistance, consider contacting OVHcloud support. They might be able to provide additional insights or workarounds specific to your situation. OVHcloud support can also help escalate the issue to the appropriate teams within OVHcloud, ensuring that it receives the necessary attention.

Conclusion

The issue of inconsistent network ID formats between the ovh_cloud_project_network_private and ovh_cloud_project_instance resources in the OVH Terraform provider can be a significant obstacle for users managing their cloud infrastructure. The discrepancy between the non-UUID format returned by ovh_cloud_project_network_private and the UUID format expected by ovh_cloud_project_instance results in deployment errors and frustrates the automation of instance creation within private networks.

However, by understanding the root cause of the problem and implementing the suggested workarounds, users can mitigate the impact of this issue. The primary workaround involves using the subnet ID, which is a UUID, instead of the network ID in the network.private.network.id attribute. This approach ensures that the OVHcloud API receives the expected UUID format, allowing instances to be created successfully within the private network.

In addition to implementing workarounds, it is crucial to report the issue to the OVH Terraform provider maintainers. This helps ensure that the bug is addressed in future releases of the provider. Keeping the provider up-to-date is also essential, as updates often include bug fixes and improvements that can resolve such issues. Furthermore, contacting OVHcloud support can provide additional assistance and help escalate the issue if necessary.

By taking these steps, users can effectively manage their OVHcloud resources using Terraform, even in the face of such inconsistencies. Addressing these issues not only improves the user experience but also contributes to the robustness and reliability of the OVH Terraform provider. As the provider evolves, it is expected that such inconsistencies will be resolved, further streamlining the management of OVHcloud resources through Terraform.
