Crash when $clog2 is Used in the Declaration Proto Module

This article addresses a critical crash issue encountered in Veryl when using the $clog2 function within the declaration of a proto module. This issue, identified in Veryl version 0.16.1-nightly (0f86f5a 2025-07-07), can halt the compilation process and disrupt development workflows. This comprehensive analysis delves into the problem, provides a clear explanation, offers a code example to reproduce the error, and discusses potential workarounds and solutions. Understanding this issue is crucial for Veryl developers aiming to leverage the $clog2 function for calculating address widths and other logarithmic-related parameters within their hardware designs.

Understanding the Crash

The crash occurs during the Veryl build process when the $clog2 system function is used to calculate the value of a constant within a proto module declaration. The Veryl compiler, during its analysis phase, encounters an unexpected None value while attempting to resolve the $clog2 expression. This leads to a panic and termination of the compilation process. The root cause of the issue appears to stem from limitations in the analyzer's ability to handle certain system functions or expressions within the context of a proto module's constant declaration. Specifically, the analyzer seems unable to properly resolve the $clog2 function call when it's used to define a constant's value directly within the module's parameter list.

Debugging Information:

The provided error message and stack trace give valuable insights into the location and nature of the crash. The panic originates in crates/analyzer/src/handlers/check_var_ref.rs on line 63, specifically due to an Option::unwrap() call on a None value. This indicates that the analyzer expected a value to be present at a certain point during the evaluation of the $clog2 expression, but instead encountered a missing value (None). The stack trace further reveals the call chain leading to the crash, starting from the veryl_analyzer crate and traversing through various modules related to parsing and semantic analysis of the Veryl code. This information helps pinpoint the specific part of the compiler that is failing and provides clues for potential fixes.

Reproducing the Issue

To reproduce the crash, consider the following Veryl code snippet:

proto module protoA #(
    const DEPTH : u64 = 1,
    const ADDR_WIDTH : u64 = $clog2(DEPTH+1)
)();

This code defines a proto module named protoA with two generic parameters: DEPTH and ADDR_WIDTH. The ADDR_WIDTH parameter is intended to be the base-2 logarithm of DEPTH + 1, calculated using the $clog2 system function. When this code is compiled using the Veryl compiler (version 0.16.1-nightly (0f86f5a 2025-07-07)), it triggers the described crash. The command used to build the code and the resulting error message are shown below:

$ RUST_BACKTRACE=1 veryl build

The output of the command reveals the panic and the stack backtrace, confirming the issue. The RUST_BACKTRACE=1 environment variable instructs Rust to include detailed stack information in the error message, which is essential for debugging.

Analyzing the Error

Based on the error message and stack trace, the crash occurs during the semantic analysis phase of the Veryl compilation process. The Veryl analyzer attempts to resolve variable references and evaluate expressions within the proto module declaration. When it encounters the $clog2(DEPTH + 1) expression, it fails to retrieve the necessary information to compute the logarithm, leading to the unwrap() call on a None value and the subsequent panic. The analyzer might not be fully equipped to handle system function calls like $clog2 within the context of a proto module's constant declaration, especially when those calls depend on other constants defined within the same module.

Workarounds and Solutions

While this issue is present in Veryl version 0.16.1-nightly, there are several workarounds and potential solutions to consider:

1. Calculate $clog2 Outside the Proto Module

One workaround is to calculate the logarithm outside the proto module declaration and then pass the result as a generic parameter. This approach avoids the direct use of $clog2 within the module's parameter list.

module top #(
    const DEPTH : u64 = 1,
    const ADDR_WIDTH : u64 = clog2(DEPTH+1) // clogg2 function can be implemented in top module.
) () {
    protoA #( .DEPTH(DEPTH), .ADDR_WIDTH(ADDR_WIDTH) ) i0();
}

function clog2(x : u64) -> u64 {
    if (x <= 1) {
        return 0;
    } else {
        let mut result : u64 = 0;
        let mut value : u64 = x;
        while (value > 1) {
            value = value >> 1;
            result = result + 1;
        }
        return result;
    }
}

proto module protoA #(
    const DEPTH : u64 = 1,
    const ADDR_WIDTH : u64 = 1
)();

In this example, the clog2 function is defined within the top-level module, and its result is passed as the ADDR_WIDTH parameter to the protoA module. This approach circumvents the issue by performing the $clog2 calculation in a context where the analyzer can correctly resolve the expression.

2. Use a Constant Expression within the Proto Module

Another possible workaround is to use a simple constant expression instead of $clog2 directly within the proto module. For instance, if the depth is known at compile time, you can manually calculate the logarithm and use its value as the ADDR_WIDTH.

proto module protoA #(
    const DEPTH : u64 = 1,
    const ADDR_WIDTH : u64 = 1 // Manually calculated clog2(1+1) = 1
)();

This approach is suitable when the depth is fixed or when the logarithm can be precomputed. However, it might not be flexible enough for cases where the depth is a configurable parameter.

3. Report the Issue and Monitor for Fixes

The most effective long-term solution is to report the issue to the Veryl development team. This allows them to investigate the root cause and implement a fix in a future release. You can report the issue on the Veryl project's issue tracker (e.g., GitHub Issues). Provide detailed information about the problem, including the code snippet that triggers the crash, the Veryl version, and the error message. Regularly monitor the issue tracker for updates and fixes related to this problem.

Implications and Best Practices

This issue highlights the importance of careful testing and debugging when using system functions and complex expressions within proto module declarations. While proto modules offer a powerful way to define parameterized hardware components, it's crucial to be aware of potential limitations in the compiler's ability to handle certain constructs. By understanding these limitations and employing appropriate workarounds, Veryl developers can continue to leverage proto modules effectively while avoiding unexpected crashes.

Best Practices:

Test Thoroughly: Always test your Veryl code thoroughly, especially when using system functions or complex expressions in proto module declarations.
Simplify Expressions: If possible, simplify expressions within proto modules to avoid potential issues.
Use Workarounds: If you encounter a crash, explore workarounds such as calculating values outside the proto module or using constant expressions.
Report Issues: Report any bugs or unexpected behavior to the Veryl development team to help improve the compiler.
Stay Updated: Keep your Veryl installation up-to-date to benefit from bug fixes and new features.

Conclusion

The crash encountered when using $clog2 in the declaration of a proto module in Veryl version 0.16.1-nightly is a significant issue that can disrupt the development process. By understanding the cause of the crash, employing the provided workarounds, and following best practices, Veryl developers can mitigate this problem and continue to create robust and efficient hardware designs. Reporting the issue to the Veryl development team is crucial for ensuring a permanent fix and improving the overall stability of the language.
