Introduction

This article addresses a common issue encountered with Adaptec Ultra160 PCI SCSI controllers (specifically models 19160, 29160(N), 39160, AHA-3960D, and AIC-7892/7899) on Windows NT 4.0: the system's failure to boot from a SCSI drive connected to the controller. This problem can be frustrating, as the drive is often detected in the SCSI BIOS, but the OS boot process either hangs or throws an error indicating that the system disk cannot be found. This comprehensive guide explores the potential causes of this issue and provides detailed troubleshooting steps to help you resolve it.

Understanding the Problem: Boot Failures with Adaptec Ultra160 SCSI Controllers

When dealing with boot failures involving Adaptec Ultra160 SCSI controllers on Windows NT 4.0, it's crucial to systematically investigate the potential causes. The core issue manifests as the system's inability to initiate the operating system boot sequence from a SCSI drive connected to the controller. While the drive might be recognized within the SCSI BIOS during the system's Power-On Self-Test (POST), the subsequent attempt to load Windows NT 4.0 from the drive falters. This can present itself as a system hang, often accompanied by a blank screen or a frozen cursor, or as an error message specifically indicating that the boot disk is not accessible or cannot be found. The error message might vary depending on the specific system configuration and the stage at which the boot process fails, but the underlying problem remains consistent: the system cannot successfully access and load the operating system from the designated SCSI boot drive. Identifying the root cause requires a methodical approach, considering both hardware and software aspects of the system.

Initial Checks: Verifying Hardware and Basic Settings

Before diving into more complex troubleshooting steps, it’s essential to rule out basic hardware issues and configuration errors. A systematic approach to these initial checks can save time and effort in the long run. Begin by meticulously verifying the physical connections of all components. Ensure that the SCSI cables are securely connected to both the Adaptec controller and the SCSI drive. Loose or improperly seated cables can lead to intermittent connectivity issues that manifest as boot failures. Next, confirm the proper termination of the SCSI chain. SCSI technology relies on proper termination to prevent signal reflections that can disrupt communication. Typically, the devices at the physical ends of the SCSI chain need to be terminated. This might involve setting jumpers or switches on the SCSI devices themselves or using external terminators. Incorrect termination is a common cause of SCSI-related problems. The SCSI ID of each device on the bus is also critical. Each device must have a unique ID to avoid conflicts. Most Adaptec controllers use SCSI ID 7 for themselves, so ensure that the boot drive and any other SCSI devices have distinct IDs (0-6 or 8-15, depending on the controller). Review the drive settings, particularly any jumpers or configuration options related to boot selection or drive parameters. Consult the drive’s documentation to ensure that these settings are correct for your system. Finally, if possible, test the SCSI drive on another controller or system to confirm that the drive itself is functioning correctly. This helps isolate whether the issue lies with the drive or the Adaptec controller and its configuration.

Detailed Steps for Initial Hardware Verification

  1. Cable Connections: Carefully inspect the SCSI cables connecting the Adaptec controller to the SCSI drive. Ensure they are firmly seated in their connectors on both ends. Look for any signs of damage to the cables, such as frayed wires or bent pins. If possible, try using a different SCSI cable to rule out a faulty cable as the cause.
  2. SCSI Termination: Understand that SCSI termination is crucial for proper SCSI bus operation. The devices at the physical ends of the SCSI chain must be terminated. This often involves setting jumpers or switches on the SCSI devices themselves. Some controllers also support automatic termination or require an external terminator. Consult the documentation for your specific devices to ensure correct termination settings. Common termination issues include unterminated buses, incorrect termination impedance, or conflicts between internal and external terminators. Experimenting with different termination configurations might be necessary to find the optimal setup.
  3. SCSI ID Conflicts: Each SCSI device on the bus must have a unique SCSI ID, typically a number between 0 and 7 (or 0 and 15 for wide SCSI). The Adaptec controller usually defaults to SCSI ID 7. Ensure that your boot drive and any other SCSI devices connected to the controller have distinct IDs to prevent conflicts. Use the SCSI BIOS utility or the Adaptec Storage Manager (ASM) to check and modify SCSI IDs if necessary. Conflicts can cause unpredictable behavior, including boot failures and data corruption.
  4. Drive Settings and Jumpers: Check the physical settings on the SCSI drive itself. Some drives have jumpers or switches that control boot selection, drive parameters, or other settings. Refer to the drive's documentation to verify that these settings are appropriate for your system configuration. Incorrect settings can prevent the drive from being recognized as a boot device or cause compatibility issues with the controller.
  5. Drive Functionality Test: If feasible, connect the SCSI drive to another SCSI controller or system to verify its functionality. This helps isolate whether the problem lies with the drive itself or with the Adaptec controller, its drivers, or its configuration. If the drive works correctly on another system, it suggests that the issue is specific to the Adaptec controller setup on your Windows NT 4.0 system.

Driver and Software Considerations

If the hardware checks out, the next step is to investigate driver and software-related issues. Incompatible or corrupted drivers can often lead to boot problems, especially in older operating systems like Windows NT 4.0. The first step is to ensure that you have the correct drivers for your Adaptec Ultra160 SCSI controller installed. These drivers should be specifically designed for Windows NT 4.0 and compatible with your controller model (19160, 29160, 39160, AHA-3960D, or AIC-7892/7899). You can typically find these drivers on the Adaptec website or on the driver CD that came with the controller. Make sure to download the latest version available, as newer drivers often include bug fixes and compatibility improvements. If you suspect that the current drivers are corrupted or incompatible, try reinstalling them. This involves removing the existing drivers through the Device Manager and then installing the new ones. Sometimes, conflicts can arise between different drivers or software components on your system. To rule out this possibility, try booting Windows NT 4.0 in Safe Mode. Safe Mode loads only the essential drivers and services, which can help you determine if a third-party driver or software is causing the problem. If the system boots successfully in Safe Mode, it suggests that a driver conflict is likely. In this case, you can try disabling non-essential drivers and services one by one to identify the culprit. Another potential issue is the SCSI BIOS settings. The Adaptec controller has its own BIOS, which controls the low-level communication with the SCSI devices. Make sure that the SCSI BIOS is enabled and configured correctly. You can usually access the SCSI BIOS setup utility by pressing a specific key (e.g., Ctrl+A) during the boot process. Within the SCSI BIOS, verify that the boot drive is recognized and that the boot order is set correctly. You might also need to adjust other settings, such as the synchronous transfer rate or the disconnection options, depending on your specific hardware configuration.

Detailed Steps for Driver and Software Troubleshooting

  1. Driver Verification and Update: The first critical step in resolving boot issues with Adaptec Ultra160 SCSI controllers on Windows NT 4.0 is to meticulously verify the installed drivers. Navigate to the Device Manager, locate the Adaptec controller, and examine the driver details. Ensure that the driver version corresponds to the correct model (19160, 29160, 39160, AHA-3960D, or AIC-7892/7899) and is specifically designed for Windows NT 4.0. Visit the Adaptec website or consult the driver CD that accompanied the controller to download the latest available drivers. Newer driver versions often include crucial bug fixes, compatibility enhancements, and performance optimizations. Outdated or incorrect drivers can lead to a myriad of problems, including boot failures and data corruption. After downloading the appropriate drivers, proceed with the installation process, which typically involves running a setup program or manually updating the drivers through the Device Manager.
  2. Driver Reinstallation: If you suspect that the existing drivers are corrupted, damaged, or otherwise causing issues, a clean reinstallation is often the best course of action. To begin, uninstall the current Adaptec drivers through the Device Manager. This ensures that any potentially problematic files or registry entries are removed from the system. After uninstalling the drivers, restart your computer. During the restart, Windows NT 4.0 might attempt to automatically reinstall drivers, but it's essential to prevent this and manually install the drivers you downloaded in the previous step. Follow the instructions provided with the drivers to complete the installation. A clean reinstallation ensures that the drivers are installed correctly and without any conflicts from previous installations. This can resolve many driver-related boot issues.
  3. Safe Mode Boot: Windows NT 4.0's Safe Mode is a valuable diagnostic tool for troubleshooting boot problems. Safe Mode starts Windows with a minimal set of drivers and services, which can help isolate whether a third-party driver or software is causing the boot failure. To boot into Safe Mode, press the F8 key repeatedly during the system startup process until the Windows NT Boot Menu appears. Select the
